S type load cell joint bearing

Hoist ring screw for S type tension load cells

The ZMMLB weighing module is designed for spoke type load cells up to 100t capacities. The load cell is with high accuracy and high stability pancake type. Stainless steel construction is optional. Features: Capacity 0.5t-100t Pancake type load cell Easy installation Nickel plated alloy steel Optional features: Stainless steel construction

The ZMX1 is a self-aligning complete with a zinc plated, steel mounting flange. Low profile in design it ensures precise load introduction in applications subject to thermal expansion or vibration. The ZMX1 is widely used in hopper and tank weighing systems, mixing vessel weighing systems. Features: Capacity 0.05t-20t Shear beam load cell Easy inst1

The ZMZX1 is column type compression mounting kit. The load cell offers fast signalling times and optimal transparency in dosing and weighing processes. With an output signal of 2.0 mV/V, load levels of up to 100 t, accuracy classes up to C3 and high-quality alloy steel, it has a wide range of potential applications.  Features: Capacity 15t-101

The ZMX7 is bending beam load cell mounting kit. The load cell offers fast signalling times and optimal transparency in dosing and weighing processes.  Features: Capacity 5kg-500kg High precision Easy and fast installation Nickel plated alloy steel Optional features: Stainless steel construction

The ZMLBA is high precison spoke type load cell designed for both tension and compression force measurement. Nickel plated alloy steel can make protection class achieve IP67. The load cell is suitable for testing machines and special measuring equipment. Stainless steel construction is optional. Features: Capacity 2t, 5t, 10t High accuracy High sta1

The ZMPF is alloy steel construction and adhesive sealed single point type load cell with IP66 protection. It is suitable for floor scales, counting scales, packing machines and similar electronic weighing devices or testing machines. Features: Capacity 50kg-2000kg High accuracy High stability Nickel plated alloy steel Optional features: Stainless 1

The S beam load cell provides good restraint to possible movement of the automation and in many cases. The small size gives excellent performance for high capacity loading. The output is rationalized to facilitate multiple-cell application. ZMSA is contructed of stainless steel and is potted to IP67 providing excellent protection against moisture a1
