Compression load cell

The ZMLB is spoke type load cell designed for both tension and compression force measurement. Nickel plated alloy steel can make protection class achieve IP67. The shear beam structure gives load cell high performance of linearity. Zhimin offers ODM&OEM service. Features: Capacity 200kg-60t High accuracy Low profile Nickel plated alloy steel IP1

The ZMNH model load cell is designed as RTN structure. This structure has really high accuracy but compact size. Compared with other types, ZMNH is most effective and stable. The load cell is usually used with adapter kits which can be offered as well. Features： Capacity 1t-330t RTN design High accuracy Compact size Optional features： Hermetically 1

The ZMMC2 brake pedal force sensor is designed to measure load applied to the brake, accelerator or clutch pedal. Zhimin's brake pedal load cells  are manufactured to be of excellent quality, so that your application will be reliable, durable, accurate and precise. Features： Capacity 500-2000N High accuracy Low profile Nickel pl1

The ZMDZT is an ultra high capacity, alloy or stainless steel compression load cell. This product is specifically designed to be used in the tank weighing assembly and available in capacities up to 6500KN. In the ZMDZT assembly this load cell provides a simple solution to high capacity container weighing.  Features: Capacity 600KN-6500KN Multi1

The ZMLBA is high precison spoke type load cell designed for both tension and compression force measurement. Nickel plated alloy steel can make protection class achieve IP67. The load cell is suitable for testing machines and special measuring equipment. Stainless steel construction is optional. Features: Capacity 2t, 5t, 10t High accuracy High sta1

The ZMNZT is double flanges type compression load cell, capacity from 300KN up to 5000KN. Construction using special steel. Efficient internal protection against the strong induced currents from lightning.  The ZMNZT model is manufactured to maintain its performance capabilities in external environmental conditions. Its application i1

The ZML2 is large force capacity pancake or spoke type compression load cell, capacity from 100t up to 1000t. The load cell is widely used in universal testing machine and construction force measure.  Features: Capacity 100t-1000t High accuracy High stability Nickel plated alloy steel Optional features: Stainless steel construction

The ZMMC4 is donut type force sensor which is available in a wide range of standard capacities from 5kg through to 2000kg. The ZMMC4 is configured for compression force measurement acting on cylinders, bolts or shafts. A range of internal through-hole diameters is available. The outer and inner diameter can be customized based on client's requireme1
