1. RTN structure.
2. High accuracy, big capacity but compact size.
3. Adapter kits can be offered as well.
Compact size
1. RTN structure.
2. High accuracy, big capacity but compact size.
3. Adapter kits can be offered as well.
PARAMETER |
VALUE |
UNIT |
Standard capacities (Emax) |
1-330 |
T |
Rated output-R.O. |
2.85 |
mV/V |
Zero balance |
1 |
±% of rated output |
Non linearity |
0.05 |
±% of rated output |
Hysteresis |
0.05 |
±% of rated output |
Non-repeatability |
0.03 |
±% of rated output |
Creep error (30 minutes) |
0.03 |
±% of rated output |
Zero return (30 minutes) |
0.03 |
±% of rated output |
Temperature effect on min. dead load output |
0.0026 |
±% of rated output/℃ |
Temperature effect on sensitivity |
0.0015 |
±% of rated output/℃ |
Compensated temperature range |
-10 to +40 |
℃ |
Operating temperature range |
-20 to +60 |
℃ |
Safe overload |
150 |
% of R.C |
Ultimate overload |
200 |
% of R.C |
Excitation, recommended |
10 |
Vdc |
Excitation, maximum |
15 |
Vdc |
Input resistance |
1450±10 |
Ohms |
Output resistance |
1400±3 |
Ohms |
Insulation resistance |
5000 |
Mega-Ohms |
Material |
Alloy steel |
|
Protection class |
IP67 |
|
